Fonestar
Fonestar SONORA-8TN-subwoofer (Black)
Fonestar

Fonestar SONORA-8TN-subwoofer (Black)

Bestelnummer 14028
20 op voorraad

POWER
180 W maximum, 120 W RMSPOWER

SPEAKERS
8'' paper cone subwoofer with water-resistant treatment

FREQUENCY RESPONSE
50-300 Hz (-10 dB)

100V TAPPINGS
120 W RMS@100 V
60 W RMS@100 V
30 W RMS@100 V
15 W RMS@100 V

IMPEDANCE
Low Z: 8 Ohm

SENSITIVITY
90 dB @ 1 W/1 m (100 Hz)

MAXIMUM SOUND PRESSURE
110 dB @ max. W/1 m

PROTECTIONS
IP-66
IEC 60068-2-11 Environmental Test (Salt mist)


MATERIAL
ABS (UV resistant)
Powder coated aluminium grille
Weatherproofed mount
Stainless steel screws

SWITCH
W selector in high Z and low ZSWITCH

CONNECTORS
Euroblock in and out for cable 0.25 - 2.5 mm² cross section

TEMPERATURE RANGE
-10ºC ~ 60ºC

COLOUR
Black (RAL 9005)

DIMENSIONS
Loudspeaker: 235 x 380 x 200 mm depth
Mount wall plate: 102 x 165 mm
Loudspeaker with mount: 305 mm depth
